Corner Production Line

Features of Corner Production Line

• Automated Corner Forming‌: HYRUN's robotic arm achieves ±0.15mm precision in 90°/45° corner production (20-30 pieces/minute).

• Multi-Material Compatibility‌: Processes galvanized steel, aluminum, and stainless steel (0.4-2.0mm thickness) without tool change.

• Smart Vision System‌: HYTECH™ CCD cameras automatically detect and correct material misalignment in real-time.

• Modular Design‌: Expandable with punching/notching units (3-minute connection via standardized interfaces).

• Energy-Saving Operation‌: Regenerative braking system reduces power consumption by 25% compared to conventional models.

Steps to Use and Points to Note of Corner Production Line

• Material Loading‌: Feed metal coils into HYRUN's auto-leveling decoiler, ensuring smooth unwinding (max. 2.5mm thickness).

• Program Selection‌: Choose corner profiles (90°/135°) via HYTECH™ touchscreen with preset parameters for different materials.

• Precision Forming‌: Monitor servo-driven rollers forming corners at 25 pieces/minute (±0.2mm tolerance).

• Quality Inspection‌: Verify dimensional accuracy every 50 pieces using built-in laser measurement.

• Safety Maintenance‌: Clean forming rollers daily and check hydraulic pressure weekly (maintain 12±0.5MPa).
